Features
1. Aluminium alloy case ,dry-type,excellent heat dissipation.
2. Metallized polypropylene film, filled with heat conducting compound.
3. Less stray inductance,good stability,reliability and lifetime
4. TÜV&TCE. Certificate
Applications
DC filtering for:windmills,solar power station,high voltage frequency
convertr,electric locomotive,subway and light rail.etc.
Features
1. Aluminium alloy case ,dry-type,excellent heat dissipation.
2. Metallized polypropylene film, filled with heat conducting compound.
3. Less stray inductance,good stability,reliability and lifetime
4. TÜV&TCE. Certificate
Applications
DC filtering for:windmills,solar power station,high voltage frequency
convertr,electric locomotive,subway and light rail.etc.
DKMJ-M DC Filter Capacitor
Tailor made service available upon request.
Refernce STANDARD:IEC 61071-2007
Electrical Specifications
Capacitance(CN): 450μF
Capacitance Tolerance: ±10%
Voltage Range(UN): 1200Vd.c.
Time constant(RC): ≥20,000s
Operating temperature: -40℃~+85℃
Hot spot temperature: ≤+85℃
Life expectancy: 100,000hours(UN, θhotspot≤70℃)
Test Voltage between terminals: 1.5UN (10s, 20°C±5°C)
Test Voltage between terminals and case: 3000Va.c. (10s, 50Hz, 20°C±5°C)
DKMJ-M DC Filter Capacitor outline drawing
For more information, please contact EECTECH and discuss your needs with us.
