Fatigue driving, unable to predict the height of the vehicle and the height of the height limiting device (height limiting pole, bridge cave) are the main reasons for the RV, bus and truck to hit the height limiting device. In addition to cause casualties and property losses, such accidents also bring bad social impact

Based on stereo vision, se2 can accurately detect the height of height limiting device and give the driver warning even if there is no signboard. It is especially suitable for urban and country roads.

SE2 perceive the road environment in front of the vehicle in real time. When there is a height limiting bar, tunnel or overpass that the vehicle can not pass, SE2 will send sound and visual warning to the driver to help the driver reduce the collision accidents caused by unfamiliar vehicle height or distraction.

Installation Position

Product parameters

Part 1, Stereo Camera Parameters
ITEM	parameters
Focus	8mm
Measure range	3m~60m
Baseline	300px
Dynamic range	120dB
Resolution	1280*720
FOV	HFOV38°
Transmission mode	RJ45, CAN，RS485，GPS
Voltage	9~36 V
Power	5 W
Storage temperature	-40℃~90℃
Working temperature	-40℃~90℃
Image frame rate	12.5 FPS

Part 2, Warning Display
ITEM	parameters
Screen type	IPS TFT
Contrast ratio	400cd/m2
Working voltage	5V
Resolution	240x320
Power	<1W
Storage temperature	-40℃~85℃
Working temperature	-20℃~70℃
